Name: Hedman Hedders® - Tight Tubes Street Rod Headers
Brand: Hedman Hedders
SKU: sp249604
Price: 480.26 USD
Availability: InStock

Specifications

Series	Tight Tubes™
Header Material	Mild Steel; Steel
Finish	HTC Polished Silver Ceramic-Metallic; Uncoated
Primary Diameter	1.625"; 2"
Collector Diameter	2.5"; 3"
Flange Thickness	0.375"; 0.3125"
Tuned	No
Crossover Pipe Included	No
Gasket or Seal Included	Yes
Quantity	1 Pair; Sold as a pair.
Inlet Port Shape	Oval; Square
Primary Tube Gauge	16-gauge; 16G
Port shape	Oval; Square
Bolts/Studs Included	Yes
Catalytic Converter(s) Included	No
Collector Attachment	3-bolt flange; Stock flange
Collector Diameter (in.)	2.50; 3.00
Collector Reducer Exit Diameter	2.500 in.
Collector Reducers Included	Yes
Flange Style	Standard
Flange Thickness (in.)	0.31 in.; 0.38 in.
Gaskets Included	Yes
Header Color	Silver ceramic coated; Temporary non-high temperature paint
Header Style	Block hugger
Motor Mounts Included	No
Primary Tube Outside Diameter (in.)	1 5/8 in.; 2 in.
Transmission Mount Included	No
Weld-Up	No

Includes

Header(S)
New Bolts and Gasket(S) To Head
Reducer(S) and Hardware
Instructions

Features

Lowest Profile Header Collector Available
Made of High Quality Materials
Works Where Ordinary Hedders Won’t Fit
Patented Collector
Produces More Power Than Standard Block Huggers

Product Details

Tight Tubes Street Rod Headers by Hedman Hedders®. Professional car builders and seasoned gearheads use Hedman’s innovative 4-into-1 TIGHT TUBES™ because the collector tucks the header tubes and hook-ups against the engine block for more component clearance than ordinary street rod hedders.

The larger volume collector design provides exhaust flow that surpasses standard block hugger design headers.

Hedman Hedders® - Catalogs Made In USA Hedman Hedders Authorized Dealer Product lines About us

Warranty

Hedman Hedders® products are covered by a Limited Lifetime Warranty, during which its products are warranted to be free from defects in material or workmanship. This Warranty does not apply to any products that have been subjected to misuse, mishandling, misapplication, neglect (including but not limited to improper maintenance), improper installation, or alterations.

The Warranty is granted to the end-user and applies to products which are purchased, installed, and used for the purposes for which they are originally designed. This Warranty covers defects arising under normal use and does not cover malfunctions or failures resulting from misuse, abuse, neglect, improper installation, or incorrect maintenance.

During the Warranty period, Hedman Hedders will repair or replace, at no charge, a product that is defective in materials or workmanship. Hedman Hedders reserves the right to either repair or replace a defective component at its discretion and reserves the right to substitute an equivalent product under the terms of this Warranty.

Magnuson-Moss Warranty Act:

Legally, a vehicle manufacturer cannot void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)) Learn More
