Name: Wilwood® 120-13236 - Forged Superlite® Radial Mount Driver Side Brake Caliper
Brand: Wilwood
SKU: mpn135593422
Price: 327.45 USD
Availability: InStock

Vehicle Fitment

This part is universal

Fits Models with 355.5mm (14") x 32mm (1.25") Brake Rotors.

Specifications

Caliper Material	Aluminum
Caliper Finish	Gray Anodized
Caliper Construction	Fixed
Caliper Mount Side	Driver Side
Caliper Type	Forged Superlite (FSL6R)
Driving Style	Performance / Racing
Mount Type	Radial
Pad Area	8.2 in²
Pad Plate	7420
Caliper Total Piston Area	4.04 in²
Piston Material	Stainless Steel
Piston Quantity	6-Piston
Piston Size	1.62"/1.12"/1.12"
Brake Pad Volume	4.9 in³
Maximum Rotor Width	1.35"
Maximum Rotor Diameter	14"
Minimum Rotor Diameter	11.75"

Features

Premium grade aluminum alloy body
Internal fluid ports that eliminate the external fluid cross-over tubes
Stainless steel pistons for corrosion resistance
Proudly manufactured in the United States

Product Details

Forged Superlite® Radial Mount Driver Side Brake Caliper (120-13236) by Wilwood®. The Superlite 6R caliper series is the benchmark in asphalt short track, late model, modified and open wheel competition. It also enjoys prominence in a variety of road-race, rally and sport driving applications. The new FSL6R model series is the latest innovation to this Superlite family of calipers. It has been redesigned with internal fluid ports that eliminate the external fluid cross-over tubes. The transfer tube has been replaced with two additional bleed screw assemblies which allow differential bore models to have a left hand and right hand orientation, but no leading or trailing configuration is required.

Installation

Wilwood® - Forged Superlite® Radial Mount Driver Side Brake Caliper Installation Instructions

The FSL6R has been redesigned with internal fluid ports that eliminate the external fluid cross-over tubes. The transfer tube has been replaced with two additional bleed screw assemblies which allow differential bore models to have a left hand and right hand orientation, but no leading or trailing configuration is required. The most noteworthy feature of all the FSL6R caliper models is the exceptional strength and reduced weight of the forging. With assembled weights just at 4.4 pounds, the caliper body design in itself is a product of computer generated solid modeling and stress analysis technology. Each caliper features closed end bridges with a radial transition down to the main body and piston bore housings. The elimination of machined steps and sharp shoulders in this critical area provides a measurable increase in overall body strength and resistance to deflection under load. Every FSL6R body is stress-flow forged from a premium grade aluminum alloy billet.

Wilwood® - Forged Superlite® Radial Mount Driver Side Brake Caliper Installation Instructions Wilwood® - Forged Superlite® Radial Mount Driver Side Brake Caliper Features Wilwood® - Finishes Wilwood® - Catalog Wilwood® - Products Comparison Wilwood® - Tech Tips Guide Wilwood® - Warranty Information Made In USA Wilwood Authorized Dealer Product lines FAQ About us

Brand:

Wilwood

Part Number:

120-13236

UPC:

889545003116

Alternate MPN:

12013236

Warranty

Do not drive on untested brakes. Brakes must be tested after installation or maintenance.

Make sure pedal is firm: Hold firm pressure on pedal for several minutes, it should remain in position without sinking. If pedal sinks toward floor, check system for fluid leaks. DO NOT drive vehicle if pedal does not stay firm or can be pushed to the floor with normal pressure.
At very low speed (2-5 mph) apply brakes hard several times while turning steering from full left to full right, repeat several times. Remove the wheels and check that components are not touching, rubbing, or leaking.
Carefully examine all brake components, brake lines, and fittings for leaks and interference.
Make sure there is no interference with wheels or suspension components.
Drive vehicle at low speed (15-20 mph) making moderate and hard stops. Brakes should feel normal and positive. Again check for leaks and interference.
Always test vehicle in a safe place where there is no danger to (or from) other people or vehicles.
Always wear seat belts and make use of all safety equipment.

General Warnings:

RACING EQUIPMENT AND BRAKES MUST BE MAINTAINED AND SHOULD BE CHECKED REGULARLY FOR FATIGUE, DAMAGE, AND WEAR. DO NOT OPERATE ANY VEHICLE ON UNTESTED BRAKES! ALWAYS UTILIZE SAFETY RESTRAINT SYSTEMS AND ALL OTHER AVAILABLE SAFETY EQUIPMENT WHILE OPERATING THE VEHICLE.
