Name: UAC® UN0890KTC - HVAC Unit Case Assembly
Brand: Universal Air Conditioner
SKU: mpn5259090132
Price: 639.80 USD
Availability: InStock
Rating: 1 (1 reviews)

Vehicle Fitment

Information is not available

Specifications

Amps	6
Angle	90 Degree
Blade Qty	10
Bottle (Oz)	8
BTU	18853
Clocking	12
Color	clear
Compressor Type	SD709
Construction Type	Aluminum
Construction Type	Parallel Flow
Contains Leak Detection Dye	No
Control Valve (Y/ N)	N
Cooling Capacity	4750 Kcal./H
Core Depth (mm)	18
Core Height (mm)	282
Core Length/Width (mm)	490
Depth (mm)	18
Diameter (mm)	240
Diameter (mm)	60
Discharge Port (mm)	42433
Fan CFM	330
Fin Height (mm)	10
Fitting Size	10
Fitting Size	8
Fitting Size	6
Fitting Type	Bulkhead Beadlock
Fitting Type	Female O-Ring Beadlock
Fluid Qty	8 oz
Fuse Plug (Y/ N)	Y
Gauge Line (mm)	40
Grooves	2
Height (mm)	140
Height (mm)	508
Hose ID	13/32
Hose Size	10
Hose Size	6
Hose Size	8
Hoses Included	No
Inlet (mm)	19
Inlet (mm)	9
Inlet Size	45724
Inlet Thread Size	43228
ISO Viscosity Grade	46
Length (mm)	199
Length (mm)	403
Outlet (mm)	16
Outlet (mm)	9
Outlet Size	45724
Outlet Thread Size	43228
Pulley Diameter (mm)	125
Refrigerant Type	R134A
Rows	4
RPM	1800-2100
Sight Glass (Y/ N)	Y
Speed	3
Suction Port (mm)	41828
Thermostat Type	Mechanical
Thread Size	42433
Type	Polyalkylene
Viscosity	46
Voltage	12
Weight (g)	4500
Width (mm)	305
Width (mm)	335

Features

Helps maintain a desired temperature inside your car
Made of durable materials
Ensures reliable performance
Guarantees high efficiency
Provides long lasting service life

Product Details

HVAC Unit Case Assembly by UAC®. UAC’s line of hose components includes the adapters, fittings and seals that are necessary for the proper function of an A/C System. They are produced at top tier facilities with strong quality control procedures so that UAC is able to offer you a product that will truly last. The products by Universal Air Conditioner ensure comfortable temperatures inside the cabin of your vehicle every time you are behind the wheel. Exceptional reliability, excellent performance, and long lasting operation are what you can expect from these products.

The products by Universal Air Conditioner provide comfortable driving for you and your passengers all year round maintaining the desired temperature inside the cabin of your car, truck or SUV. These products deliver a superior combination of perfect fit, high efficiency, and long lasting service life. UAC products are made of durable materials which guarantee their reliable performance and excellent durability.

Universal Air Conditioner® - Information Universal Air Conditioner Authorized Dealer Product lines Warranty About us

Brand:

Universal Air Conditioner

Part Number:

UN0890KTC

UPC:

711307088836

Warranty

Universal Air Conditioner, Inc (UAC) products made in Asia that fail because of defect in material or workmanship, within a period of 1 year from day of purchase from UAC, will be replaced to the original purchaser at no charge. All other products will be subject to that manufacturer's warranty. There are no other warranties expressed, implied or intended other than the 1 year from day of purchase warranty.

This warranty is subject to the following conditions and exclusions:

1. Valid Proof of Purchase. Warranty requests are only accepted with valid proof of purchase from UAC.

2. Proper Installation. Proper installation in accordance with furnished instructions and/or acceptable industry installations methods, as stated in service manuals must be followed by installation personnel. Install the clutch on Compressors purchased without a clutch and set the clutch air gap per OEM specifications. Check clutch electrical circuit for proper voltage per OEM specifications. After compressor installation, turn the compressor shaft a minimum of 10 revolutions to remove excess lubricant from the compressor. Evacuate entire A/C system for a minimum of 45 minutes. Recharge with the proper refrigerants: R134a or R12. When replacing scroll compressors, it is common that debris from the original compressor gets lodged in the condenser and causes the replacement compressor to experience a catastrophic failure. This can be identified by holes and large cracks in the body of the fitted replacement compressor. To avoid a warranty from being denied by UAC, the installer must flush the evaporator and replace the following: Compressor with clutch, Multi-pass, parallel flow condensers (Parallel Flow Condensers cannot be flushed), Drier or Accumulator, Expansion Valve or Orifice Tube, Seals, and O-rings. The work order submitted to UAC as part of the warranty request must indicate that all of these parts were replaced.

3. Exclusions. The following conditions automatically void the warranty obligations: abuse, improper use, shipping damage, damage from dropping, dead batteries, cosmetic damage, failure to service at recommended intervals and failure to follow printed instructions. Clogged or broken expansion valves and/or orifice tubes, malfunctioning fuses, relays, switches, and electrical components are excluded from warranty coverage. Compressor warranty is void unless the drier/accumulator, orifice tube and/or expansion valve is replaced upon installation and system is flushed using generally accepted methods. If the condenser is a parallel-flow type, it must be changed. The proper lubricant must be used. Units returned without lubricant and not properly capped are excluded from warranty coverage. UAC does not accept products for Stock Adjustment.

4. Service Tools and Equipment. Warrantied products will be repaired and returned to the customer. This includes vacuum pumps, leak detectors, manifold gauge sets and recovery, recycle and recharge equipment.

Magnuson-Moss Warranty Act:

Legally, a vehicle manufacturer cannot void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)) Learn More

Reviews

(1)

Only authorized customers can leave a review on our website. We would love to know what you like or dislike about the product. Share your opinion on product quality, appearance, installation, and other characteristics.

1-1 of 1 Reviews

Sort by

1 of 5

Didn't Last 2 Minutes.

I bought it since my old heater core was the original out of the factory and the entire top split open, was leaking terribly. Well I installed this one, started the old truck up, and 2 minutes later it was leaking worse than the last one, leaking right out the arms, all across the top of my box right onto the passenger floor. Absolutely worthless and not worth the scrap it's made out of.
