LuK® DMF117 - Dual Mass Flywheel

7 reviews|Item # mpn575204860
Vehicle Specific
    Select Vehicle
    Replaces Original (OE) Part #:55558265, 55353856, 55576200
    Authorized Dealer
    $264.20
    In Stock (12) - Ships Tomorrow 06.12.26
    See similar products
    Have a Question? Ask a Specialist
    888-577-6964Live Chat

    Vehicle Fitment

    Saab

    Specifications

    Number of teeth, starter ring gear
    135
    Torque Capacity DMFW
    13.858 inch
    Torque Capacity DMFW
    352 mm
    Centering diameter / dowel hole
    10.236 inch
    Centering diameter / dowel hole
    260 mm
    Crank To Friction Surface
    1.618 inch
    Crank To Friction Surface
    41.1 mm
    Ring Gear Number
    L-09180-0076-02
    Overall Casting O.D.
    11.378 inch
    Overall Casting O.D.
    289 mm
    Flywheel Thickness [mm]
    2.539 inch
    Flywheel Thickness [mm]
    64.5 mm
    Dowel Hole Pattern
    5
    Flywheel Friction Surface Inner diameter
    6.063 inch
    Flywheel Friction Surface Inner diameter
    154 mm
    Ring Gear Thickness
    .433 inch
    Ring Gear Thickness
    11 mm
    Ring Gear To Friction Surface
    1.618 inch
    Ring Gear To Friction Surface
    41.1 mm
    Ring Gear Mounting O.D.
    10.508 inch
    Ring Gear Mounting O.D.
    266.9 mm
    Crank Hole Dia.
    .425 inch
    Crank Hole Dia.
    10.8 mm
    Dowel hole diameter
    .236 inch
    Dowel hole diameter
    6 mm
    Bolt hole PCD crankshaft
    2.717 inch
    Bolt hole PCD crankshaft
    69 mm
    Cup depth, secondary flywheel
    -.311 inch
    Cup depth, secondary flywheel
    -7.9 mm
    Ring Gear Major Dia.
    11.250 inch
    Ring Gear Major Dia.
    285.75 mm
    Bolt hole PCD clutch pres.plte
    10.236 inch
    Bolt hole PCD clutch pres.plte
    260 mm
    Bolt Hole Pattern
    2
    Flywheel friction surface outer diameter
    9.331 inch
    Flywheel friction surface outer diameter
    237 mm
    I.D. for Pilot
    1.386 inch
    I.D. for Pilot
    35.2 mm

    Features

    • Engineered and manufactured to OE specifications
    • All new components - including ring gear and dowel pins
    • Perfectly balanced
    • Precision-machined from premium grade cast iron
    • Superior quality friction surface
    • Excellent heat-absorbing capacity
    • Order from the comfort of your home or office
    • 8 mounting bores
    • With pilot bearing
    • No SVHC present

    Product Details

    Dual Mass Flywheel (DMF117) by LuK®. LuK dual mass flywheels absorb engine vibrations before they are transmitted to the driveline where they can create gear rattle. These units feature a built-in damper designed to isolate engine torque spikes and prevent transmission damage. By design, dual mass flywheels cannot be resurfaced.

    Installation

    LuK® - Installation Instructions

    The flywheel is an integral part of a clutch replacement. In today’s tightly packaged clutch systems, flywheels can easily be machined beyond their usable life – a critical flaw that would not be evident until after the clutch is installed. Improper machining can also cause interference, no release and slipping problems. Pairing your LuK RepSet with a new LuK flywheel is a smart, cost-effective alternative to resurfacing.

    LuK® - ManualLuK® - Installation InstructionsLuK Authorized DealerInstallationAdditional InformationAbout us
    Brand:
    LuK
    Part Number:
    DMF117
    UPC:
    884109881094
    OE Numbers:
    55558265, 55353856, 55576200
