Fox® 985-62-002 - 0"-2" 2.0 Performance Series Front IFP Coilover

Name: Fox® 985-62-002 - 0"-2" 2.0 Performance Series Front IFP Coilover
Brand: Fox
SKU: mpn4946797373
Price: 314.95 USD
Availability: InStock
Rating: 4.6 (5 reviews)

5 reviews|Item # mpn4946797373

Vehicle Specific

Notes:

It’s recommended to replace shock or strut in pairs (passenger and driver side at the same time)
Spring not included
Reuses stock mounting hardware

Authorized Dealer

$314.95

In Stock (51)

See similar products

Have a Question? Ask a Specialist

888-577-6964Live Chat

Vehicle Fitment

Chevy

GMC

Specifications

Front Lift Height	0"-2.0"
Adjustable Mounting Bracket Included	No
Adjustable Valving	No
Body Diameter (in.)	2.000
Bushing Material	Spherical bearing
Coilover Shock Type	Non-adjustable
Coilover Springs Included	No
Gas Charged	Yes
Hardware Included	No
Quantity	Sold individually.
Suspension Height Adjustment	0.0-2.0 in. raised
Shock Absorber Internal Design	Monotube
Shock Absorber Type	Gas Charged
Shock Absorber Damping Type	Normal
Shock Absorber Adjustment Type	Without Adjustment
Shock Absorber Height Adjustment Type	Threaded Spacer
Shock Absorber Compressed Height	16.9" (429.3)
Shock Absorber Extended Height	20.92" (431.4)
Shock Absorber Stroke Length	4.02"
Shock Absorber O.D.	2.0"
Shock Absorber Shaft O.D.	0.625"
Shock Absorber Reservoir	Internal Floating Piston (IFP)
Shock Absorber Lower Mount Type	Eyelet
Shock Absorber Upper Mount Type	Stock
Shock Absorber Material	Aluminum (6061-T6)
Finish	Silver
Material	Aluminum

Features

2.0" Metal impacted 6061-T6 aluminum will resist rust over time
Clear-anodized for a durable finish
Internal IFP mono-tube reservoir design separates shock oil from the high-pressure nitrogen
Black-anodized, CNC-machined 6061-T6 billet aluminum components
5/8" hard chrome plated heat-treated alloy steel shaft
Race-developed high-flow piston design
Application specific valving to maximize performance
Redundant sealing pack system main seal, wiper seal, scraper seal
JM92 Advanced Suspension Fluid for improved performance at variable temperatures
Large diameter, heavy-duty spherical bearing
Direct replacement for stock and aftermarket lifts kits mounting

Product Details

2.0 Performance Series Front IFP Coilover with 0"-2" Front Lift Height (985-62-002) by Fox®. Quantity: 1 per Pack. Offroad Performance Series coil-over shocks take advantage of Fox tried and-true coil-over design and incorporates features like rubber braided steel hoses with high-flow fittings for improved durability and performance. Pinch-bolt spring preload rings allow easy ride height and preload adjustment and retain the top quality racing coil selected to deliver your optimal spring rate. Fox Offroad Performance Series coil-over shocks will suspend your vehicles weight and provide Fox race-proven, performance damping technology to tame the toughest terrain. If you are looking for a comfortable ride and predictable offroad handling, look no further.
