Name: DS18® X4 - 1400W 4-Channel Class D Amplifier
Brand: DS18
SKU: mpn4716874907
Price: 215.95 USD
Availability: InStock

Vehicle Fitment

This part is universal

Specifications

Model	X4
RMS Porwer @ 2 ohm	140W x 4 CH
RMS Porwer @ 4 ohm	70W x 4 CH
RMS Power @ 4 ohm Bridge	220W x 2 CH
Frequency Response	20-20Khz
Signal/Noise Ratio	90 dB
Selectable X-Over	LPF/FLAT/HPF
Fixed LPF Frequency	80Hz
Low Lever Input Range	0.2-5V
Input Configaration	2CH/4CH
Leds Indicate Working Status	Power/Protection
Dimensions	140.8 L x 82.4 W x 34H (mm)

Features

High in power, efficient in performance, reliable in service
User-friendly design, ergonomic handle, solid construction
Will become your right hand in DIY and repair projects
Made to meet stringent quality and safety requirements

Product Details

1400W 4-Channel Class D Amplifier by DS18®. Micro amps are a great power solution for an audio enthusiast that doesn't have alot of room to spare for big bulky amps. In this case, you want to maximize your size to power ratio so you can get as much power you can with as little space as possible. DS18 now has the DS18® newest micro amp, the X4. The X4 is about as large as a cell phone and packs a whopping punch. This tiny amp pushes out 70w x 4 @4ohm, 140w x 4 @2ohm, and 220w x 2 @4ohm bridged. Now you need to sacrifice very little space for multiple power options that can power most mids, highs, and tweeters.

DS18® - Catalog 2020 Made In USA DS18 Authorized Dealer

Brand:

DS18

Part Number:

UPC:

810005183185

Warranty

1-Year Limited Warranty

DS18 warrants this product to be free from defects in material and workmanship under normal use and conditions for a period of one year from the date of purchase. This warranty covers any defects in materials and workmanship and warranty only applies to the original purchaser and is not transferable. DS18 will repair any part of your product that proves to be defective in materials or workmanship. In the event repair is not possible, DS18 will replace the product in question. If it is deemed necessary DS18 will either replace the entire product with a refurbished unit or it will be replaced with a model that is similar in price if that model is no longer available.

This warranty does not cover the cost for removal and reinstallation of any kind. This warranty is void and inapplicable DS18 deems that the product was abused or misused; including but not limited to Speaker product that has been improperly-powered, causing thermal coil failure and/or mechanical failure, damage caused by accident, mishandling, improper installation, negligence, normal wear and tear, excessive water or heat damage, and freight damage. DS18 is not responsible for any damages to a consumer's vehicle or person from a product failure. The warranty is void if DS18 deems the product was installed or used improperly. DS18 shall not be responsible for any incidental or consequential damages.

Refurbished units have a 90-day warranty.

Magnuson-Moss Warranty Act:

Legally, a vehicle manufacturer cannot void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)) Learn More
