DS18® ZXI-354 - 3-1/2" 120W 4 Ohm Full-Range Speaker

Name: DS18® ZXI-354 - 3-1/2" 120W 4 Ohm Full-Range Speaker
Brand: DS18
SKU: mpn4933717528
Price: 59.95 USD
Availability: InStock
Rating: 3 (2 reviews)

2 reviews|Item # mpn4933717528

Missing Fitment Information

Fitment notes:

Fitment data unavailable. Compatibility is not guaranteed. Please purchase by part number only.

Notes:

Sold individually.

Authorized Dealer

$59.95

In Stock (753) - Ships in 2 to 3 days

See similar products

Have a Question? Ask a Specialist

888-584-4732Live Chat

Vehicle Fitment

Information is not available

Specifications

Nominal Diameter	3.5"
Nominal Impedance	4 Ohm
RMS Power	40W
Max Power	120W
Sensitivity	89 dB
Frequency Response	120Hz-20KHz
Recommended HI Pass Crossover	140Hz
Voice Coil Diameter	1"/25.5mm
Voice Coil Former Material	KSV
Winding Material	EISV
Cone Material	Glass fiber
Surround Material	Rubber
Basket Material	Steel
Magnet Material	Barium Ferrite
Magnet Weight	10.9 oz/310g
Equivalent Volume	0.55L
Excursion (one way)	1.4mm
Free Air Resonance	140Hz
Mechanical Factor	7.08
Electrical Factor	1.37
Total Factor	1.15
Mechanical Mass	3.2g
Mechanical Compliance	402mm/N
BL Factor	2.938
Cone Area	32cm2
DC Resistance	4.2 Ohm
Mechanical Mass w/o air	3.0g
Overall Diameter	3.50"/89mm
Overall Depth	1.65"/42mm
Front Mount Baffle Cutout	2.80"/71mm
Mouting Depth	1.49"/37.8mm
Motor Diameter	2.36"/60mm

Features

The ZXi line is a complete line of amps, subs, mids, and tweeters so you can match all your equipment up to be the same for an amazing show quality look
3.5" 1 way 4 Ohm speaker requiring 40W RMS and 120W Max power handling that gives amazing sound from low to extremely high volume
1 -Way design will be sure to give you a full range of frequencies for an amazing audio experience to remember

Product Details

3-1/2" 120W 4 Ohm Full-Range Speaker by DS18®. The ZXI series is the go to DS18 line for great sounding audio that not only has very high volume, but also amazing sound quality for an amazing price. The ZXI 354 is 3.5", 4 Ohm coaxial speaker designed for mid tier audio enthusiasts to the extreme as they have an amazing range of frequencies and loudness. The 1 way design will ensure that you receive a full range of frequencies for an audio experience that you will truly remember.

DS18® - Product Catalog Made In USA DS18 Authorized Dealer

Brand:

DS18

Part Number:

ZXI-354

UPC:

810005187824

Alternate MPN:

ZXI354

Warranty

1-Year Limited Warranty

DS18 warrants this product to be free from defects in material and workmanship under normal use and conditions for a period of one year from the date of purchase. This warranty covers any defects in materials and workmanship and warranty only applies to the original purchaser and is not transferable. DS18 will repair any part of your product that proves to be defective in materials or workmanship. In the event repair is not possible, DS18 will replace the product in question. If it is deemed necessary DS18 will either replace the entire product with a refurbished unit or it will be replaced with a model that is similar in price if that model is no longer available.

This warranty does not cover the cost for removal and reinstallation of any kind. This warranty is void and inapplicable DS18 deems that the product was abused or misused; including but not limited to Speaker product that has been improperly-powered, causing thermal coil failure and/or mechanical failure, damage caused by accident, mishandling, improper installation, negligence, normal wear and tear, excessive water or heat damage, and freight damage. DS18 is not responsible for any damages to a consumer's vehicle or person from a product failure. The warranty is void if DS18 deems the product was installed or used improperly. DS18 shall not be responsible for any incidental or consequential damages.

Refurbished units have a 90-day warranty.

Magnuson-Moss Warranty Act:

Legally, a vehicle manufacturer cannot void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)) Learn More

Reviews

(2)

Only authorized customers can leave a review on our website. We would love to know what you like or dislike about the product. Share your opinion on product quality, appearance, installation, and other characteristics.

1-2 of 2 Reviews

Sort by

5 of 5

Great Speakers

Great speakers, they sound amazing. Originally bought to replace the front speakers in my truck, both blown, the rear speakers still work and sound great. They are factory. But now I'm thinking about replacing them with DS18s as well because they sound so good. Don't fret when you get them delivered, they don't come with a plug. Simply cutting the plug off of the wiring in the truck, stripping the wire and wrapping around the piece of metal on the speaker where you'd think the plug would be does the trick. I would recommend these to anyone, and would be my first choice if I ever get another vehicle. And not to mention the price. I was amazed at how little they cost me, the factory speakers cost more than these! I'm rocking the bumper sticker they came with!

DS18® - Pro GM Series 6-1/2" 580W 8 Ohm Midrange Speaker with Bullet Diffuser

Posted by Braley (Shelbyville, MI) / July 25, 20222000 Chevy Silverado 2500

1 of 5

Sad

It can't handle power sad 500 watts cerwin vaga abt to pop it.

DS18® - Pro Series 8" 500W 4 Ohm Midrange Speaker with Bullet Diffuser

Posted by Anthony J (Eureka, CA) / July 18, 2021
