Detroit Iron® DPRGM-312-90GTREDWD - Wiring Diagrams

Specifications

Features

• Developed to preserve valuable data about antique and classic rides
• Made with the utmost care for your specific year, make and model
• Designed to provide the exact copy of the original manual

Product Details

Wiring Diagrams by Detroit Iron®. This 1990 Chevrolet & GMC R-V-P Truck Wiring Diagrams is a high-quality, licensed PRINT reproduction of the service manual authored by GM Corporation and published by Detroit Iron. This OEM factory manual is 17 x 11 inches, COMB bound, shrink-wrapped and contains 400 pages of comprehensive mechanical instructions with detailed diagrams, photos and specifications for the mechanical components of your vehicle such as the engine, transmission, suspension, brakes, fuel, exhaust, steering, electrical and drive line. Service / repair manuals were originally written by the automotive manufacturer to be used by their dealership mechanics. The following 1990 Chevrolet, GMC models are covered: Blazer, R1500 Suburban, R2500 Suburban, R3500, V1500 Suburban, V2500 Suburban, V3500, P30, Jimmy, P3500. This factory-written Detroit Iron shop manual is perfect for the restorer or anyone working on one of these vehicles.
