Detroit Iron® DPRGM-153-76TWD - Wiring Diagrams

Specifications

Features

• Developed to preserve valuable data about antique and classic rides
• Made with the utmost care for your specific year, make and model
• Designed to provide the exact copy of the original manual

Product Details

Wiring Diagrams by Detroit Iron®. This 1976 Chevrolet GMC Truck Wiring Diagrams (Models 10-1500 Thru 30-3500 ) - 11x26 inch Foldouts is a high-quality, licensed PRINT reproduction of the service manual authored by General Motors Corporation and published by Detroit Iron. This OEM factory manual is 8.5 x 11 inches, paperback bound, shrink-wrapped and contains 24 pages of comprehensive mechanical instructions with detailed diagrams, photos and specifications for the mechanical components of your vehicle such as the engine, transmission, suspension, brakes, fuel, exhaust, steering, electrical and drive line. Service / repair manuals were originally written by the automotive manufacturer to be used by their dealership mechanics. The following 1976 Chevrolet, GMC models are covered: C10, C10 Suburban, C20, C20 Suburban, C30, K10, K10 Suburban, K20, K20 Suburban, G10, G20, G30, P10, P20, P30, C80, D80, C15, C15 Suburban, C25, C25 Suburban, C35, Jimmy, K15, K15 Suburban, K25, K25 Suburban, G15, G25, G35, P15, P25, P35. This factory-written Detroit Iron shop manual is perfect for the restorer or anyone working on one of these vehicles.
