Detroit Iron® DPRGM-153-74TWD - Wiring Diagrams

Specifications

Features

• Developed to preserve valuable data about antique and classic rides
• Made with the utmost care for your specific year, make and model
• Designed to provide the exact copy of the original manual

Product Details

Wiring Diagrams by Detroit Iron®. This 1974 Chevy LD,MD,HD Trucks Wiring Diagrams - 11x26 inch Foldouts is a high-quality, licensed PRINT reproduction of the wiring diagrams authored by Chevrolet Motor Division and published by Detroit Iron. This OEM factory manual is 8.5 x 11 inches, STAPLED bound, shrink-wrapped and contains 38 pages of 11x26 inch foldout detailed factory wiring diagrams. Wiring Diagrams were originally written by the automotive manufacturer to be used by their dealership mechanics. The following 1974 Chevrolet models are covered: Blazer, C10 Suburban, C20 Suburban, K10 Suburban, K20 Suburban, C10 Pickup, C20 Pickup, C30 Pickup, K10 Pickup, K20 Pickup, K30 Pickup, C50, C60, H70, H80, J70, J80, H90, J90. This factory-written Detroit Iron wiring diagram set is perfect for the restorer or anyone working on one of these vehicles.
