Aeromotive® 18147 - Fuel Tank System

Name: Aeromotive® 18147 - Fuel Tank System
Brand: Aeromotive
SKU: mpn4565379427
Price: 808.18 USD
Availability: InStock

0 reviews|Item # mpn4565379427

Vehicle Specific

Notes:

This is a Race Only product that is to be used solely for competition. It cannot be used on vehicles that are operated on public streets, roads or highways. Its use is limited to closed-course and open-course racing that is formally sanctioned by a recognized racing organization. Any other use, including recreational off-road use, could be in violation of local, state and federal laws. Shipping Restriction: CA, NY, ME.

Authorized Dealer

$808.18

In Stock (4) - Ships in 24 to 48 hrs

See similar products

Have a Question? Ask a Specialist

888-577-6964Live Chat

Vehicle Fitment

Ford

Specifications

Baffled Sump	Yes
Fuel Pump Included	Yes
Fuel Sump Welded on Tank	No
Hardware Included	No
Lock Ring Kit Included	Yes
Outlet Quantity	One
Capacity	20 Gallons
Flow Rate	53 GPH/200 LPH
Length	33.000"
Width	40.000"
Height	11.000"
Material	Steel
Finish	Silver Painted
Quantity	1 Piece

Includes

Innovative baffling/tray system to control fuel slosh
Preinstalled 73-10 Ohm Universal Fuel Level Sending Unit

Features

Perfect for EFI and carbureted engines
OEM appearance and 16-gallon capacity
Durable, powder-coat silver exterior finish
High flow, quiet 200 Stealth in-tank fuel pump
Wide, lateral internal surge baffle
Large, EFI friendly fuel pump reservoir
73-10 Ohm fuel level sending unit
Billet hat with ORB-06 outlet, return and vent ports
Fully assembled out of the box, ready to install
View Installation Instructions

Product Details

Fuel Tank System by Aeromotive®. Why an Aeromotive 200 Stealth Fuel Tank? These Aeromotive 200 Stealth fuel tank features our 200 LPH Stealth electric fuel pump mounted to our CNC machined, billet aluminum hat and hanger assembly. With 200 lph flow, using a turbine pumping mechanism for increased durability and quiet operation, the Stealth Tank is equipped with the most proven, capable, quiet operating fuel pump available in it’s class. All Aeromotive Stealth fuel tanks feature an innovative baffle and tray design to control fuel slosh, ensuring good street drivability even even at lower fuel levels. A fuel level sending unit with the correct ohm rating for the factory gauge in the dash comes pre-installed. The 340 Stealth pump has its own pre-pump filter sock for protection and is supported by a billet hat with robust electrical bulkhead connections and ORB-06 outlet, return and vent ports, ensuring high flow capacity and a positive, leak free seal at any pressure.

Aeromotive is here with excellent products that are available at a competitive price. The company does its utmost to provide the best possible solutions for your needs. All products by Aeromotive are made with expert care and created by professionals to meet all your requirements. The company does not accept compromises when it is going about quality, so you can be sure that all products have only first-rate quality. With many years of manufacturing experience, Aeromotive is the name you can trust.

Aeromotive® - Information Aeromotive® - Warranty Aeromotive® - Catalogs Made In USA Aeromotive Authorized Dealer Product lines FAQ About us

Brand:

Aeromotive

Part Number:

18147

UPC:

684980009422

Warranty

Aeromotive warrants its products to be free from defects in materials or workmanship for a period of 1 year. The warranty period begins on the date the product is delivered. The warranty is granted to the end-user and applies to products which are purchased, installed, and used for the purposes for which they are originally designed. This warranty covers defects arising under normal use and does not cover malfunctions or failures resulting from misuse, abuse, neglect, improper installation, or incorrect maintenance. During the warranty period, Aeromotive will repair or replace, at no charge, a product that is defective in materials or workmanship. Aeromotive reserves the right to either repair or replace a defective component at its discretion and reserves the right to substitute an equivalent product under the terms of this warranty.

Magnuson-Moss Warranty Act:

Legally, a vehicle manufacturer cannot void the warranty on a vehicle due to an aftermarket part unless they can prove that the aftermarket part caused or contributed to the failure in the vehicle (per the Magnuson Moss Warranty Act (15 U.S.C. 2302(C)) Learn More
