Avant Garde Series

Avant Garde ART Series Wheels

ENGINEERING

Our newest Advanced Rim Technology (A.R.T.) is the latest manufacturing process that incorporates traditional monoblock wheel casting methods with spin forming technology to drastically improve the material properties and enhances the overall strength of our wheels. The A.R.T. process impacts the micro-structure of aluminum by utilizing three hydraulic rollers to apply pressure to form the inner rim area after the wheel has been casted. The rollers move down the barrel, applying pressures to stretch, compress, and form the entire wheel barrel, ultimately increasing the tensile strength and elongation properties.

The end product is a lighter, stronger wheel that has an increased load capacity and shock resistance over the traditional cast aluminum wheel. A.R.T. provides up to a 25% weight reduction compared to a traditional cast wheel. The M610 weights for 19? sizes start at 21 lbs per wheel while the weights for 20? sizes start at 22 lbs per wheel.

TIMELESS DESIGN WITH MODERN TECHNOLOGY

A classic seven-spoke concaved monoblock design utilizing our Advanced Rim Technology that not only rigidifies, but also reduces the weight of the wheel drastically without sacrificing performance.

BESPOKE FITMENTS AVAILABLE

Take full control of your fitment. Providing you with the option of achieving the most aggressive fitment possible without compromising performance.

ENDLESS FINISHING OPTIONS

The finishing possibilities are limitless. Available in polished and custom powdercoated options, customize your M610 to achieve the specific look you are envisioning.

STEP 1STEP 1.An initial casting unique to Flow Forging Technology is placed onto a steel rim and mold and prepped to be processed.
STEP 2STEP 2. Extensive heat and pressure is applied using three individual rollers to shape the aluminum to the rim mold. The individually shaped rollers fortifies the barrel to the specified width and density allowing for a stronger wheel using less material.
STEP 3STEP 3. The molecular compound of the aluminum significantly hardens in a streamline direction resulting in a wheel with a higher impact tolerance and considerably lighter in weight.
Avant Garde Classic Series Wheels

In order to maintain the highest quality possible, Avant Garde utilizes the latest in computer aided engineering and testing in the creation of wheels. The wheels are tested in the computer before they are put into production. Finite Element Analysis (FEA) visualizes the stress points in the wheel designs, allowing designers to quickly define the critical design parameters and make adjustments that optimize the weight/strength ratio without compromising the styling. Stringent testing to the JWL standard ensures that quality is never compromised. To detect even the most minute flaws, the wheels are put under pressure in a purpose designed water tank and X-rayed for hidden imperfections. The constant attention to detail and the stringent testing ensure that Avant Garde always provides customers with the highest quality wheels

M310 Gunmetal with Machined FaceM310 Gunmetal
M580 Satin SilverM580 Satin Silver
M510 Satin SilverM510 Satin Silver
  • Finite Element Analysis Derived Designs
  • Lightening Pockets Standard on All Wheels
  • Torque Mounting Pad Ring Standard on All Wheels
  • Compatible with OEM TPMS Sensors
  • 1-Year Warranty on Finish
  • Lifetime Warranty on Structure
  • Timeless Mesh Design
  • Plug-And-Play Fitments
  • Endless Finishing Options
  • Classic Series
Avant Garde Forged Series Wheels

Forging is a process that shapes the raw aluminum blank into the near-final form of the wheel under many tons of hydraulic pressure. A 250-ton rotary forge press forces 6061 T6 aerospace aluminum billet blanks into a steel die. Not only does the forging process shape the metal, it changes it dramatically, compressing it into a denser, stronger form with internal grain that follows the contour of the finished forging, for the ultimate in strength. Only detail machining is necessary to bring the wheel to its final contour. In the case of the Function Series wheels, that means the wheel is forged in several components, including a barrel and center that are fastened together by exotic titanium bolts. Final lightening of the center is accomplished by spoke beam contouring and back pad contouring. Available in 17", 18", 19" and 20" diameters.

F451 Polished Copper with Chrome LipF451 Polished Copper
F433 Technica TitaniumF433 Technica Titanium
F450 Brushed CandyF450 Brushed Candy

The design of these wheels is done with the latest technology of Finite Element Engineering, a process that allows the wheel designer to "build" a wheel in the computer and stress it with the loads it will see when in service. The software shows graphically where the stresses are concentrated in the wheel. By trimming metal here and there, and adding some where needed, it's possible to very quickly come to an optimum design, one that's the lightest and strongest possible. All of this is done in a few hours or days in the computer, instead of laboriously making prototypes and testing them until they fail. This accelerated design process generates the strongest, lightest wheels in the industry, and allows Avant Garde to develop many vehicle-specific styles and fitments in a very short period of time.

  • Performance Driven Engineering emphasizes function over form
  • Step Lip configuration is stronger and reduces weight in comparison to reverse configuration (flat lip) wheels
  • Titanium Hardware - Standard
  • Backpad Pocketing - Standard
  • Spoke Beam Contouring - Standard
  • Aerospace Grade 6061-T6 forged aluminum for optimum strength-to-weight ratio
  • Precision CNC production to your specifications for any custom application
  • OE TPMS and mounting hardware compatible
  • 1-Year Warranty on Finish
  • Lifetime Warranty on Structure
Avant Garde Luxury Series Wheels

Made with an emphasis on artistic innovation, Avant Garde Luxury Wheels are an awesome combination of sophisticated looks, exceptional strength and precision CNC machining. The AG wheels are designed to complement the aesthetics of your luxury vehicle and highlight its dominating presence.

The Avant Garde Luxury Wheel Collection represents the pinnacle of the aftermarket wheel industry. Every feature allows you to personalize your wheel so it becomes a unique reflection of your individuality. AG Luxury is an exclusive approach to define your vehicle. It will be hard to resist the temptation of having these wheels installed on your pride and joy. These stunningly looking wheels will make all the heads turn your direction as you ride.

AGL39 Matte Black with Chrome LipAGL39 Matte Black
AGL41 Polished Rose GoldAGL41 Polished Rose Gold
AGL55 PolishedAGL55 Polished

Every wheel from AG Luxury collection is made utilizing in-house precision CNC machining and manufactured from aerospace grade 6061-T6 forged aluminum which allows to achieve a super strong wheel without compromising the overall performance. Each wheel is engineered by expert AG team to provide maximum personalization. This complete personalization also concerns the finishes for all components of the wheel.

From 24K Gold plated hardware to multi-stage and multi-tone finishing on the lips and centers, every AG wheel is a true reflection of each owner's unique personality. Engineered and manufactured with individualized concave center profiles AG wheels provide a perfect balance between optimal brake caliper clearance and lip size. It means that these wheels are compatible with all brake applications ranging from standard OEM brakes to aftermarket brake kits and even ceramic brake kits.

  • Reflect each owner's unique personality
  • Aerospace Grade 6061-T6 forged aluminum for optimum strength-to-weight ratio
  • Precision CNC production to your preference for any custom application
  • Individual engineering for each design and vehicle
  • TPMS and OE mounting hardware compatible
  • Manufactured with individualized concave center profiles
  • Custom bolt patterns, offsets, and finishes
  • Engineered, manufactured, and assembled in the USA
